Automatic Steam Eye Mask Packaging Machine

Automatic Steam Eye Mask Packaging Machine

Intelligent & High-Speed Control：
PLC, touch interface, encoder, and photoelectric systems ensure simple, precise, and high-capacity operation.

Fully Automated Production：
Synchronized feeding, sealing, welding, cutting, and waste collection improve efficiency and reduce labor.

High-Quality & Safe Output：
Ultrasonic ear strap welding, precision cutting, and full safety protection guarantee durable, attractive, and safe products.

Introduction

Automatic Warmer Pad Making Machine is developed by our research and development personnel according to the demand of packing market. Can produce different kinds of steam eye mask to cater to different needs of customers.

Specifications and Parameters:

Items	YZ-220C
Roll Cutting Times	15-120times/minute
Max material Width	230mm
Raw Material	Non-woven fabric, max diameter 600mm, inner size 75mm
Compressed Air（Mpa）	0.4-0.6Mpa
Power Voltage	380V/220V 50HZ
Total Power	Around 7Kw
Overall Dimension	3850×700×1850mm（LWH）
Weight	1200Kg

Machine Features:

1. The machine realizes intelligent control through the combination of programmable controller (PLC), man-machine interface, encoder, photoelectric system, etc., and the operation is simple and intuitive.

2.Full servo synchronous control system, high-precision graphic benchmarking system. Ensuring stable operation and greatly increasing production capacity.

3. The automatic feed, synchronous feeding, rolling sealing, ultrasonic welding, rolling cutting, and automatic waste collection into rolls are synchronized by the programmable controller (PLC) output.

4.The high-speed reaction of the microcomputer is used to control the amount of glue sprayed and the speed of glue spray, so as to minimize the amount of glue used and avoid unnecessary waste.

5.Adopt automatic synchronous feeding system, easy to adjust the connection of feeding and equipment. Automatically guide positioning to ensure the synchronization and stability of the whole machine.

6.The ear strap is ultrasonically welded to make it seamlessly welded to the eye mask. The joint is firm and hard, and the belt is comfortable and soft.

7.The finished rolling cutter die adopts imported high-performance materials, special process heat treatment and precision processing. The cutter has a long service life and can be repaired. The finished product has a beautiful appearance and no burrs.

8.The whole machine adopts all-round safety protection isolation, the external raw material is easy to replace, safe to use and high in yield.

9.Automatically eliminate the used hanging ear function
